How to Install the SnapMagic Search Plugin for Eagle

1. Download Eagle (if necessary):
   https://www.autodesk.com/products/eagle/free-download/
2. Upon launching Eagle, you’ll see the Control Panel.
   Go to File > Open > Scripts > and select eagle.scr. Add the following line to the MENU area in both the BRD and SCH sections:
   '[bin/snapeda.png] SnapEDA : Run snapeda.ulp;'\
3. Download the SnapMagic Search Eagle Plugin (SnapEDA-Eagle-Plugin.zip). After unzipping, move both snapeda.ulp and json.inc into Documents > eagle > ulps.

4. Copy snapeda.png from the downloaded folder and paste it in the bin folder located inside your Eagle directory (C:\EAGLE 9.x.x\bin).
5. The SnapMagic Search plugin is now installed. When you start a new Schematic or Board, you should be able to see the SnapMagic Search icon in the top menu bar.

Note: If you are using older versions of Eagle,move both snapeda.ulp and json.inc into the ulp folder in the Eagle application directory.

How to Install the SnapMagic Search Plugin for Altium

1. Download the SnapMagic Search Altium Designer Plugin (SnapEDA-AD-Plugin.zip)
2. Double-click on the downloaded .exe file
3. Follow the steps of the setup wizard
4. Click on “Install” and then click on “Finish”
5. Open Altium Designer
6. Click on “File” from the Altium Designer main menu
7. Click on SnapMagic Search plugin and then log in with your credentials
8. Get started!

Need assistance? Contact us at [email protected].

How to Install the SnapMagic Search Plugin for KiCad

1. Download the SnapMagic Search KiCad Plugin (SnapEDA-KiCad-Plugin.zip)
2. Please follow the step below according to your operating system:

3. In KiCad, click on Edit PCB
4. In Pcbnew, click Tools -> External Plugins -> Refresh Plugins.

You will now be able to see and initiate the SnapMagic Search KiCad Plugin from within the External Plugins dropdown.

Note: This plugin is only supported by Kicad up to version 5.1.10.

Need assistance? Contact us at [email protected].

How to Install the SnapMagic Search Plugin for Autodesk Fusion in Windows

REQUIREMENTS: Python 3*

For Windows users:

1. Download the SnapMagic Search Autodesk Fusion Plugin (SnapEDA-Fusion-Plugin.zip)
2. Install the SnapMagic Search Fusion 360.msi
3. Open Autodesk Fusion > Click on Tools tab > ADD-INS > Scripts and Add-Ins > Click the Plus (+) button > Select SnapMagic Search folder.
4. A SnapMagic Search Icon will now show in the Add-Ins tab.

Note: Just in case if the installer won't work/completed unsuccessfully, a workaround would be:

1. Copy the following folder to C:\Users\your_username\AppData\Roaming\Autodesk\Autodesk Fusion\API\AddIns\SnapEDA

   SnapedaWebPlugin.py
   SnapedaWebPlugin.manifest
   Resources
   snapeda-fusion-plugin.exe


How to Install the SnapMagic Search Plugin for Autodesk Fusion in MacOS

1. Go to System Preferences > Security & Privacy > General
2. Click the Unlock icon, and select App Store and Identified Developers
3. Double-click on the DMG installer
4. Complete the steps to install the app
